Interfaz
4 10/100Mbps LAN Ports
1 10/100Mbps WAN Port
Botón: Wireless On/Off
Button, RE Button, WPS Button
Reset Button, Power On/Off Button Antenas: 3 x 9dBi
Desmontables Omni Directional Antenna
(RP-SMA)
Fuente de Alimentación
Externa: 12VDC / 1.5A
Estándares Inalámbricos: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensiones (W X D X H):
9.0 x 7.5 x 1.9 in. (227.5 x 190 x 48.3mm)
CARACTERÍSTICAS INALÁMBRICAS
Frequency: 2.4-2.4835GHz
Signal Rate: 11n: Up to 450Mbps(dynamic) 11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 450M: [email protected]% PER
130M: [email protected]% PER
108M: [email protected]% PER
54M: [email protected]% PER
Transmit Power CE:<20dBm(2.4GHz)
FCC:<30dBm
Wireless Functions:
Enable/Disable Wireless Radio, WDS Bridge,
WMM, Wireless Statistics
Wireless:
64/128/152-bit WEP / WPA / WPA2,
WPA-PSK / WPA2-PSK
CARACTERÍSTICAS DE SOFTWARE
Quality of Service WMM, Bandwidth Control
WAN Type Dynamic IP/Static IP/PPPoE/
PPTP/L2TP/BigPond PPTP/L2TP/BigPond
Management Access Control
Local Management
Remote Management
DHCP Server, Client, DHCP Client List,
Address Reservation
Port Forwarding Virtual
Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Access Control Parental Control, Local Management Control,
Host List, Access Schedule, Rule Management
Firewall Security DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
Contenido del paquete
450Mbps Wireless N High Power Router
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
Technical Support Card
